8086 Microcomputer /Microprocessor Interface & Programming Trainer Kit (Metal)Trainer Kit Electronic Training Kit 8086 for Lab
This metal trainer kit serves as comprehensive experimental equipment for courses including "Microcomputer Control Technology" and "16-bit Microcomputer Principles and Interfaces." Designed with a focus on compact systems, multifunctionality, and easy expansion, the motherboard is based on experiments from the "HL-8086 Series Microcomputer Experiment Guide."
Advanced System Architecture
The system incorporates address bus, data bus, control bus, and expansion units, allowing educational institutions to select expansion modules according to their specific requirements. This provides an excellent experimental development environment for teaching experiments, course design, and graduation projects across various colleges and universities.
Key Features & Operating Modes
Dual Operating Modes
PC-Connected Operation: Enables comprehensive debugging and running operations when connected to host software
Offline Operation: Includes built-in keyboard, display circuit, and monitoring/management program for independent operation without a PC
Advanced Debugging Capabilities
The system supports memory read/write operations, single-step execution, breakpoint setting, and full-speed debugging methods, providing complete program development and testing capabilities.
Experimental Openness & Flexibility
Experimental circuit units are designed as independent and open components, including open keyboards, displays, and serial ports. This architecture provides maximum adaptability for various experimental methodologies and teaching approaches.
Secondary Development Capabilities
The system brings out all address buses, data buses, and control buses, with the motherboard featuring expansion units. This enables users to debug custom boards and develop additional functionality through the experimental system.
Measurement Instrumentation: Equipped with a dual-channel virtual oscilloscope measuring card for comprehensive signal analysis and testing.
